Description
Features
-
-
- Sturdiness secured through the adoption of an all Axis box guide
- Highly accurate direct link and highly sturdy all-in-one structure
- Highly accurate pretension double-anchor method
- Minimized heat deformation in the main spindle
- Gearless type main spindle models are all equipped with a mill turret.
- Big Bore Spindle (TC30C Series)
-
Specifications
Units of Measure:
| Description | Unit | TC30C | TC30LC |
|---|---|---|---|
| Max Turning Dia | mm | 560 | 560 |
| Max Turning Length | mm | 720 | 1,320 |
| Chuck Size | inch | 12″ | 12″ |
| Driving Method | - | GEAR | GEAR |
| Spindle RPM | r/min | 3,000 | 3,000 |
| Spindle Output | kW | 26/22 | 26/22 |
| Spindle Torque | N.m | 1131/957 | 1131/957 |
| Travel(X/Z) | mm | 355/750 | 355/1,350 |
| Rapid Travel(X/Z) | m/min | 20/24 | 20/24 |
| Slide Type | - | BOX | BOX |
| No. of Tools | EA | 12 | 12 |
| Tool Size | mm | 25/50 | 25/50 |
| CNC | - | H/W FANUC i | H/W FANUC i |
Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalogue.
